New launched FL-355-AIO, output power up to 1W, pulse width is ~3ns, It features ultra-miniaturized design, etc

2025 06/05

FL-355nm series laser has the features of high peak power, high repetition rate, and short pulse duration, which is used in scientific research, biology, instrumentation, 3D marking, laser marking, sub-surface engraving and so on.



Wavelength (nm): 355±1

Operating mode: Passively Q-switched

Average power (mW): ≥1000

Single pulse energy (µJ)L ＞40

Pulse duration (ns) ~3

Peak power (kW) ~15

Rep. rate (kHz) ~20kHz

Transverse mode TEM00

Beam divergence, full angle (mrad) <3.5

Beam diameter at the aperture (1/e 2 , mm) ~3.0

Beam height from base plate (mm) 67.2

Warm-up time (minutes) <15

Operating temperature (℃) 10~35

Supply Voltage DC 12V25A
